Stainless steel castors

Stainless steel apparatus castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
50 18 40 70 60x60 45x45 6,5 26 G100.A80.051 G120.A80.051 G110.A80.051
75 24 60 101 60x60 45x45 6,5 25 G100.A80.076 G120.A80.076 G110.A80.076
100 28 60 136 76x70 60x50 8,3 35 G100.A80.100 G120.A80.100 G110.A80.100
125 28 70 158 76x70 60x50 8,3 35 G100.A80.126 G120.A80.126 G110.A80.126
load capacity (kg) 40 - 70 kg
Stainless steel apparatus castor

Tread
Blue-grey rubber
Wheel body
Plastic
Bearing
Plain bearing
Apparatus castor
Catalogue page: 104

Stainless steel apparatus castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
50 18 55 70 60x60 45x45 6,5 26 G100.A90.051 G120.A90.051 G110.A90.051
75 23 60 101 60x60 45x45 6,5 25 G100.A90.076 G120.A90.076 G110.A90.076
100 27 90 136 76x70 60x50 8,3 35 G100.A90.100 G120.A90.100 G110.A90.100
120 27 100 156 76x70 60x50 8,3 35 G100.A90.120 G120.A90.120 G110.A90.120
load capacity (kg) 55 - 100 kg
Stainless steel apparatus castor

Tread
Plastic
Wheel body
Plastic
Bearing
Plain bearing
Plastic wheel
Catalogue page: 104

Stainless steel apparatus castor
swivel castor swivel castor with brake

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 bolt hole-Ø (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake
50 18 40 70 12 26 G101.A80.051 G121.A80.051
75 24 60 101 12 25 G101.A80.076 G121.A80.076
100 28 60 134 12,5 35 G101.A80.100 G121.A80.100
125 28 70 156 12,5 35 G101.A80.126 G121.A80.126
load capacity (kg) 40 - 70 kg
Stainless steel apparatus castor

Tread
Blue-grey rubber
Wheel body
Plastic
Bearing
Plain bearing
Apparatus castor
Catalogue page: 105

Stainless steel apparatus castor
swivel castor swivel castor with brake

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 bolt hole-Ø (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake
50 18 55 70 12 26 G101.A90.051 G121.A90.051
75 23 60 101 12 25 G101.A90.076 G121.A90.076
100 27 90 134 12,5 35 G101.A90.100 G121.A90.100
120 27 100 156 12,5 35 G101.A90.120 G121.A90.120
load capacity (kg) 55 - 100 kg
Stainless steel apparatus castor

Tread
Plastic
Wheel body
Plastic
Bearing
Plain bearing
Plastic wheel
Catalogue page: 105

Stainless steel transport castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
80 30 100 108 95x80 80x60 9 32 H100.A90.080 H120.A90.080 H110.A90.080
100 30 130 127 95x80 80x60 9 32 H100.A90.100 H120.A90.100 H110.A90.100
125 39 130 155 95x80 80x60 9 32 H100.A90.125 H120.A90.125 H110.A90.125
150 40 200 192 129x106 105x80 11 52 H100.A90.150 H120.A90.150 H110.A90.150
200 50 200 240 129x106 105x80 11 48 H100.A90.200 H120.A90.200 H110.A90.200
load capacity (kg) 100 - 200 kg
Stainless steel transport castor

Tread
Plastic
Wheel body
Plastic
Bearing
Plain bearing
Plastic wheel
Catalogue page: 106

Stainless steel transport castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
80 28 100 108 95x80 80x60 9 32 H100.B26.080 H120.B26.080 H110.B26.080
100 30 130 127 95x80 80x60 9 32 H100.B26.100 H120.B26.100 H110.B26.100
125 32 130 155 95x80 80x60 9 32 H100.B26.125 H120.B26.125 H110.B26.125
150 35 200 192 129x106 105x80 11 52 H100.B26.150 H120.B26.150 H110.B26.150
200 45 200 240 129x106 105x80 11 48 H100.B26.200 H120.B26.200 H110.B26.200
load capacity (kg) 100 - 200 kg
Stainless steel transport castor

Tread
Red polyurethane 98+/-4 Shore A
Wheel body
Plastic
Bearing
Plain bearing
Polyurethane wheel
Catalogue page: 106

Stainless steel transport castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
80 28 70 108 95x80 80x60 9 32 H100.B32.080 H120.B32.080 H110.B32.080
100 32 110 127 95x80 80x60 9 32 H100.B32.100 H120.B32.100 H110.B32.100
125 39 130 155 95x80 80x60 9 32 H100.B32.125 H120.B32.125 H110.B32.125
150 40 200 192 129x106 105x80 11 52 H100.B32.150 H120.B32.150 H110.B32.150
200 50 200 240 129x106 105x80 11 48 H100.B32.200 H120.B32.200 H110.B32.200
load capacity (kg) 70 - 200 kg
Stainless steel transport castor

Tread
Blue polyurethane, 85+/-4 Shore A
Wheel body
Plastic
Bearing
Plain bearing
Rubber wheel
Catalogue page: 106

Stainless steel transport castor
swivel castor swivel castor with brake fixed castor

Description

stainless steel fork,
double row ball collar in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
80 30 60 108 95x80 80x60 9 32 H100.B43.080 H120.B43.080 H110.B43.080
100 30 80 127 95x80 80x60 9 32 H100.B43.100 H120.B43.100 H110.B43.100
125 35 100 155 95x80 80x60 9 32 H100.B43.125 H120.B43.125 H110.B43.125
150 40 140 192 129x106 105x80 11 52 H100.B43.150 H120.B43.150 H110.B43.150
200 50 200 240 129x106 105x80 11 48 H100.B43.200 H120.B43.200 H110.B43.200
load capacity (kg) 60 - 200 kg
Stainless steel transport castor

Tread
Grey thermopl. tyre
Wheel body
Plastic
Bearing
Plain bearing
Rubber wheel
Catalogue page: 106

Stainless steel transport castor
swivel castor swivel castor with brake

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 bolt hole-Ø (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake
80 30 100 108 12,2 32 H101.A90.080 H121.A90.080
100 30 130 127 12,2 32 H101.A90.100 H121.A90.100
125 34 130 160 12,2 47 H101.A90.125 H121.A90.125
150 44 200 192 12,2 52 H101.A90.150 H121.A90.150
200 50 200 240 12,2 48 H101.A90.200 H121.A90.200
load capacity (kg) 100 - 200 kg
Stainless steel transport castor

Tread
Plastic
Wheel body
Plastic
Bearing
Plain bearing
Plastic wheel
available alternative: peg mounting
Catalogue page: 107

Stainless steel transport castor
swivel castor swivel castor with brake

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 bolt hole-Ø (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake
80 28 100 108 12,2 32 H101.B26.080 H121.B26.080
100 30 130 127 12,2 32 H101.B26.100 H121.B26.100
125 32 130 160 12,2 47 H101.B26.125 H121.B26.125
150 35 200 192 12,2 52 H101.B26.150 H121.B26.150
200 45 200 240 12,2 48 H101.B26.200 H121.B26.200
load capacity (kg) 100 - 200 kg
Stainless steel transport castor

Tread
Red polyurethane, 98+/-4 Shore A
Wheel body
Plastic
Bearing
Plain bearing
Polyurethane wheel
available alternative: peg mounting
Catalogue page: 107

Stainless steel transport castor
swivel castor swivel castor with brake

Description

  • Stainless steel fork
  • dual-row ball bearings collar in fork head

Model

  • swivel castor
  • swivel castor with brake

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 bolt hole-Ø (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake
80 28 70 108 12,2 32 H101.B32.080 H121.B32.080
100 32 110 127 12,2 32 H101.B32.100 H121.B32.100
125 39 130 160 12,2 47 H101.B32.125 H121.B32.125
150 40 200 192 12,2 52 H101.B32.150 H121.B32.150
200 50 200 240 12,2 48 H101.B32.200 H121.B32.200
load capacity (kg) 70 - 200 kg
Stainless steel transport castor

Tread
Blue polyurethane, 85+/-4 Shore A
Wheel body
Plastic
Bearing
Plain bearing
Rubber wheel
available alternative: peg mounting
Catalogue page: 107

Stainless steel transport castor


Description

  • stainless steel fork
  • double row ball collar in fork head

Model

  • swivel castor
  • swivel castor with brake

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 bolt hole-Ø (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake
80 30 60 108 12,2 32 H101.B43.080 H121.B43.080
100 30 80 127 12,2 32 H101.B43.100 H121.B43.100
125 35 100 160 12,2 47 H101.B43.125 H121.B43.125
150 40 140 192 12,2 52 H101.B43.150 H121.B43.150
200 50 200 240 12,2 48 H101.B43.200 H121.B43.200
load capacity (kg) 60 - 200 kg
Stainless steel transport castor

Tread
Grey thermopl. tyre
Wheel body
Plastic
Bearing
Plain bearing
Rubber wheel
available alternative: Stem fitting
Catalogue page: 107

Stainless steel heavy duty castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • ball bearings in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
100 35 200 133 100x120 76x76 11 41 J100.A90.100   J110.A90.100
125 40 250 175 138x110 105x75/80 10 32 J100.A90.127 J120.A90.127 J110.A90.127
125 45 550 165 140x127 114x105 11 50 J100.A90.125   J110.A90.125
150 40 350 200 138x110 105x75/80 10 40 J100.A90.152 J120.A90.152 J110.A90.152
150 48 700 200 150x150 125x125 11 55 J100.A90.150   J110.A90.150
200 50 500 250 138x110 105x75/80 10 52 J100.A90.202 J120.A90.202 J110.A90.202
200 50 900 241 150x150 125x125 11 65 J100.A90.200   J110.A90.200
250 60 1100 300 150x150 125x125 13 55 J100.A90.250   J110.A90.250
load capacity (kg) 200 - 1100 kg
Stainless steel heavy duty castor

Tread
Plastic
Wheel body
Plastic
Bearing
Plain bearing
Plastic wheel
Catalogue page: 108

Stainless steel heavy duty castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • ball bearings in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
100 37 450 140 138x110 105x75/80 10 27 J100.B15.100 J120.B15.100 J110.B15.100
125 50 700 175 138x110 105x75/80 10 32 J100.B15.125 J120.B15.125 J110.B15.125
150 48 900 200 138x110 105x75/80 10 40 J100.B15.150 J120.B15.150 J110.B15.150
200 50 900 250 138x110 105x75/80 10 52 J100.B15.200 J120.B15.200 J110.B15.200
load capacity (kg) 450 - 900 kg
Stainless steel heavy duty castor

Tread
Plastic
Wheel body
Plastic
Bearing
Plain bearing
Plastic wheel
Catalogue page: 108

Stainless steel heavy duty castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • ball bearings in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
100 55 900 140 138x110 105x75/80 10 27 J100.B16.100 J120.B16.100 J110.B16.100
125 55 900 175 138x110 105x75/80 10 32 J100.B16.125 J120.B16.125 J110.B16.125
150 55 900 200 138x110 105x75/80 10 40 J100.B16.150 J120.B16.150 J110.B16.150
200 55 900 250 138x110 105x75/80 10 52 J100.B16.200 J120.B16.200 J110.B16.200
load capacity (kg) 900 kg
Stainless steel heavy duty castor

Tread
Cast polyamide
Wheel body
Cast polyamide
Bearing
Ball bearing
Polyamide wheel
Catalogue page: 108

Stainless steel heavy duty dual castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • ball bearings in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
125 2x40 500 175 138x110 105x75/80 10 32 K100.A90.125 K120.A90.125 K110.A90.125
150 2x40 700 200 138x110 105x75/80 10 40 K100.A90.151 K120.A90.151 K110.A90.151
200 2x50 900 250 138x110 105x75/80 10 52 K100.A90.200 K120.A90.200 K110.A90.200
load capacity (kg) 500 - 900 kg
Stainless steel heavy duty dual castor

Tread
Plastic
Wheel body
Plastic
Bearing
Plain bearing
Plastic wheel
Catalogue page: 109

Stainless steel heavy duty dual castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • ball bearings in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
100 2x55 1400 150 138x110 105x75/80 10 27 K100.B16.100 K120.B16.100 K110.B16.100
125 2x55 1400 175 138x110 105x75/80 10 32 K100.B16.125 K120.B16.125 K110.B16.125
150 2x55 1400 200 138x110 105x75/80 10 40 K100.B16.150 K120.B16.150 K110.B16.150
200 2x55 1400 250 138x110 105x75/80 10 52 K100.B16.200 K120.B16.200 K110.B16.200
load capacity (kg) 1400 kg
Stainless steel heavy duty dual castor

Tread
Cast polyamide
Wheel body
Cast polyamide
Bearing
Ball bearing
Polyamide wheel
Catalogue page: 109

Stainless steel heavy duty dual castor
swivel castor swivel castor with brake fixed castor

Description

  • Stainless steel fork
  • ball bearings in fork head

Model

  • swivel castor
  • swivel castor with brake
  • fixed castor

wheel Ø (mm)
mm		 wheel width (mm)
mm		 load capacity (kg)
kg		 overall height (mm)
mm		 plate size (mm)
mm		 screwhole distance (mm)
mm		 screwhole diameter (mm)
mm		 offset (mm)
mm		 art.num.
swivel castor		 art.num.
swivel castor with brake		 art.num.
fixed castor
100 2x37 900 150 138x110 105x75/80 10 27 K100.B15.100 K120.B15.100 K110.B15.100
125 2x50 1400 175 138x110 105x75/80 10 32 K100.B15.125 K120.B15.125 K110.B15.125
150 2x48 1400 200 138x110 105x75/80 10 40 K100.B15.150 K120.B15.150 K110.B15.150
200 2x50 1400 250 138x110 105x75/80 10 52 K100.B15.200 K120.B15.200 K110.B15.200
load capacity (kg) 900 - 1400 kg
Stainless steel heavy duty dual castor

Tread
Plastic
Wheel body
Plastic
Bearing
Ball bearing
Plastic wheel
Catalogue page: 109
